CS 486/686
Course Recap
Lecture 22
Putting the term together: search, uncertainty, decisions, learning
The course in one picture
Search I — uninformed
Problem formulation
- States, actions, transition model, initial & goal states, path cost.
- Search tree explores states by expanding the frontier.
Pick the data structure for the frontier → pick the algorithm.
DFS vs BFS vs IDS
- DFS: stack → \(O(bm)\) space, not complete.
- BFS: queue → complete, \(O(b^d)\) time and space.
- IDS: DFS in increasing depth → BFS-completeness, DFS-space.
IDS combines the best of both.
Search II — heuristic + A*
The three frontier rules
- LCFS: min \(\text{cost}(n)\).
- GBFS: min \(h(n)\).
- A*: min \(f(n) = \text{cost}(n) + h(n)\).
Heuristic properties
- Admissible (\(h \le h^*\)) ⇒ A* is optimal with multi-path pruning off.
- Consistent (\(h(n) \le c(n,n') + h(n')\)) ⇒ safe to use multi-path pruning.
- Consistent ⇒ admissible (not the other way around).
Search strategy summary
| Strategy |
Frontier choice |
Complete? |
Space |
Time |
| Depth-first | Last added | No | Linear | Exp |
| Breadth-first | First added | Yes | Exp | Exp |
| Lowest-cost first | min \(\text{cost}(n)\) | Yes | Exp | Exp |
| Greedy best-first | min \(h(n)\) | No | Exp | Exp |
| A* | min \(\text{cost}(n) + h(n)\) | Yes | Exp | Exp |
A* dominates when the heuristic is informative enough to prune most of the tree.
CSPs + local search
Constraint satisfaction
- Generate-and-test is exponential — exploit problem structure.
- Backtracking: incremental, prune as soon as a constraint fails.
- Arc consistency / AC-3: shrink domains before/during search; complexity \(O(cd^3)\).
Local search
- Trade completeness for very large state spaces.
- Greedy descent / hill-climbing: always move to best neighbour.
- Beats local minima with random restarts + simulated annealing (accept worse moves with prob \(e^{-\Delta/T}\)).
Probability + independence
The four rules
- Product: \(P(A,B) = P(A\mid B)\,P(B)\)
- Sum: \(P(A) = \sum_b P(A, B{=}b)\)
- Chain: \(P(X_1,\ldots,X_n) = \prod_i P(X_i \mid X_{<i})\)
- Bayes: \(P(H\mid e) \propto P(e\mid H)\,P(H)\)
Independence
- Unconditional: \(P(A,B) = P(A)\,P(B)\).
- Conditional: \(P(A,B\mid C) = P(A\mid C)\,P(B\mid C)\).
- Tells us which terms drop out of the chain rule — the key to scaling up inference.
Bayesian networks + d-separation
Construction recipe
- Pick a variable order (causal often works best).
- Add each node; choose the smallest set of parents that makes it conditionally independent of the rest.
- Joint factorizes as \(P(X_1,\ldots,X_n) = \prod_i P(X_i \mid \mathrm{pa}(X_i))\).
3 d-separation patterns
-
Chain \(A \to B \to C\): blocked by observing \(B\).
-
Common cause \(A \leftarrow B \to C\): blocked by observing \(B\).
-
Common effect \(A \to B \leftarrow C\): blocked by not observing \(B\) or descendants.
A path is blocked ⇒ the endpoints are conditionally independent.
Inference — VE & HMM filtering
Variable elimination
- Define a factor for each CPT.
- Restrict factors to evidence.
- Multiply factors sharing a variable; sum out the hidden one.
- Normalize to get a posterior.
HMM filtering
- Recursion: \(P(S_t \mid o_{0:t}) \propto P(o_t \mid S_t)\, \sum_{s_{t-1}} P(S_t \mid s_{t-1})\, P(s_{t-1} \mid o_{0:t-1})\)
- One forward pass: \(O(t \cdot |S|^2)\) time.
HMM decoding — smoothing & Viterbi
Forward×backward smoothing
- Forward: \(\alpha_k = P(S_k \mid o_{0:k})\).
- Backward: \(\beta_k = P(o_{k+1:t-1} \mid S_k)\).
- Posterior: \(P(S_k \mid o_{0:t-1}) \propto \alpha_k\, \beta_k\).
Viterbi
- DP over the trellis, max instead of sum.
- Backtrack the argmax pointers to recover the MAP sequence.
Decision networks
Three node types
- Chance nodes — like a Bayes net (CPTs).
- Decision nodes — rectangles, no CPT, chosen by us.
- Utility node — diamond, deterministic function of its parents.
Maximum expected utility
- Policy \(\pi(d \mid \text{parents})\); MEU picks \(\pi^*\) maximizing \(\mathbb{E}[U]\).
- Evaluate by enumeration or by running VE on the DN.
- Value of information: EU gain from observing a variable before deciding.
Markov decision processes
Setup
- States, actions, transition \(P(s' \mid s, a)\), reward \(R(s)\), discount \(\gamma\).
- Policy \(\pi : S \to A\); value \(V^\pi(s) = \mathbb{E}[\sum_t \gamma^t R(s_t) \mid \pi]\).
Bellman + the two algorithms
- Bellman optimality: \(V^*(s) = R(s) + \gamma \max_a \sum_{s'} P(s' \mid s, a)\, V^*(s')\).
- Value iteration: apply the Bellman update until convergence.
- Policy iteration: evaluate (linear system) ↔ improve (greedy) — converges fast.
Reinforcement learning
Two learning regimes
- Passive ADP: follow a fixed policy, estimate \(\hat P, \hat R\), solve via PE.
- Active ADP: also pick actions — balance exploration vs exploitation (\(\varepsilon\)-greedy, softmax, optimistic init).
Model-free updates
- Q-learning (off-policy): \(Q(s,a) \leftarrow Q(s,a) + \alpha\big[R + \gamma \max_{a'} Q(s', a') - Q(s,a)\big]\).
- SARSA (on-policy): use the action actually taken instead of \(\max_{a'}\).
- ADP converges fast but needs a model; Q-learning is slower but model-free.
Supervised + unsupervised learning
Supervised
- Classification (discrete \(y\)) vs regression (continuous \(y\)).
- Bias-variance: underfit (high bias) ↔ overfit (high variance).
- Cross-validation: \(K\)-fold to pick the model complexity that minimizes held-out error.
- ERM: minimize empirical loss \(\frac{1}{N}\sum_i \ell(\hat y^{(i)}, y^{(i)})\).
Unsupervised
- k-means: alternate assign ↔ recompute centroids; pick \(k\) via elbow / silhouette.
- PCA: project onto top eigenvectors of the covariance matrix; maximize variance.
- Autoencoders & GANs: learn representations / generators with neural nets.
Decision trees + neural networks
Decision trees
- Greedy top-down split with ID3.
- Choose split that maximizes information gain \(I = H(Y) - H(Y\mid X)\).
- Stop when pure / no features / no examples.
- Interpretable, great for small tabular data.
Neural networks
- Weighted sums + non-linear activations (sigmoid, ReLU).
- Forward pass computes loss; backprop computes gradients via chain rule (\(\delta\) recursion).
- Train with SGD + momentum / Adam.
- Black box but unmatched for images, audio, text.
Notation cheat sheet
Symbols that recur across the four modules. Watch for the two collisions on the right.
| Symbol | Meaning | First seen |
|---|
| \(\gamma\) | Discount factor for future rewards | L13 (MDPs) |
| \(\pi\), \(\pi^\star\) | Policy / optimal policy | L12–L15 |
| \(V(s),\ Q(s,a)\) | State / state-action value functions | L13–L15 |
| \(H(p),\ IG\) | Entropy / information gain (\(IG = H_{\text{before}} - H_{\text{after}}\)) | L6 (entropy) · L18 (IG) |
| \(\mathcal{H}\) | Hypothesis class (ERM) | L16 |
| \(\Sigma\) | Covariance matrix (PCA) | L17 |
| \(\alpha\) | RL TD step size (L15); momentum coefficient (L21) — different meanings | L15 / L21 |
| \(\varepsilon\) | Exploration probability in \(\varepsilon\)-greedy (L15); learning rate in SGD (L21) — different meanings | L15 / L21 |
Worth a row on your two-sided study sheet.
Final exam — logistics
What to bring
- Non-programmable calculator.
- One two-sided A4 study sheet (handwritten or typed).
Format (tentative)
- Around 8 problems spanning all four modules.
- ~84 marks total; 76+ marks count as 100%.
- Pass threshold: 42 marks.
Exact details will be confirmed on the course page before exam day.
Thanks for a great term — good luck on the final!
